Jaw Crusher

---We supply full line of mining equipment and technical support

Generally Description

Jaw crusher is mainly used to crush kinds of mining stones primarily, and the largest compression resistance of the material is 320MPa. The jaw crusher is widely used in stone mining, metallurgy industry, building material, highway, railway, and chemical industry.

Main parts and characteristics

Firstly the machine’s V-belt and wheel are driven by the electric motor, then the movable jaw plate begins to move up and down by the eccentric shaft, when the movable jaw plate moves from top to bottom, the angle between fixed jaw plate and movable jaw plate becomes smaller, the material is crushed into pieces to reach the crushing target. When the movable jaw plate moves from bottom to top, the angle between fixed jaw plate and movable jaw plate becomes bigger, the movable jaw plate deviates from the fixed jaw plate under the function of drag rod and spring, at this moment, the crushed material is discharged from the bottom outlet of the crushing cavity.

Main Features

1. The deep crushing cavity increases the feeding capacity and output capacity.

2. High ratio of crushing, homogeneous final product size.

3. Adjusting the discharge opening through gasket, more convenient, it could meet different customers’ requirements.

4. Lubricate system is safe and reliable, easy to change the spare parts.

5. Simple structure, easy maintenance, energy consumption is lower.

6. Lower noise and dust.

Why choose us

1. We are Manufacturer  (Not Dealer):

All machineries from Jiangxi Hengcheng Mining Equipment Company are made by ourselves, with lower price, good quality and assured full after service. The quality guarantee is 12 months after finishing the trial run of machines which has been shipped to the buyer side. If any part (excluding easily damaging parts) is found defective in quality within warranty period, we would like to replace it for free. After warranty, spare parts can be replaced based on favorable price.

2. Training & Service:

We provide you with the prophase plan, process flow design and manufacture equipment according to your special demand.

Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.

We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.

3. We’d like to recommend a suitable model for you and send you a best quotation. So please give us some more information about your requirement in your enquiry.

What is the type and size of raw material?

What is required size of final product(mm)?

What is the capacity do you need per hour?
